Scale-Link Automation, Inc.

The BW050 series of web tension load cells sensitively detect the resultant force caused by pulling the material based on the wrap angle by being installed on the roll shaft directly and easily.

BW050 tension measuring load cells are made of stainless steel and have a wide range of capacity options depending on the application.

-Capacities: 100 kg
-Extremely robust
-Stainless steel construction
-Flange mounting
-Easy installation
-Overload protection
